Channel |
7.2 |
---|---|
Virtual Presence Speaker |
Yes |
Rated Output Power (20Hz-20kHz, 2ch driven) |
100 W (8 ohms, 0.06% THD) |
Maximum Effective Output Power (1kHz, 1ch driven) (JEITA) |
160 W (6 ohms, 10% THD) |
High Slew Rate Amplifier |
Yes |
Surround:AI |
N / A |
CINEMA DSP |
Yes |
DSP Programs |
17 |
Dialog Level Adjustment |
Yes |
Auro 3D |
N / A |
File Format |
MP3 / WMA / MPEG-4 AAC: up to 48 kHz / 16-bit, ALAC: up to 96 kHz / 24-bit, FLAC: up to 384 kHz / 24-bit, WAV / AIFF: up to 384 kHz / 32-bit, DSD: up to 11.2 MHz |
Virtual Surround Back Speaker |
Yes |
SILENT CINEMA / Virtual CINEMA DSP |
Yes |
Dolby Atmos |
Yes |
Dolby Atmos Height Virturalizer |
Yes (via future update) |
Dolby TrueHD |
Yes |
Dolby Digital Plus |
Yes |
Dolby Surround |
Yes |
DTS-HD Master Audio |
Yes |
Video adjustment |
N / A |
Dialogue Lift |
Yes |
Bi-amp capability |
Yes |
Compressed Music Enhancer |
Yes |
High-resolution Music Enhancer |
N / A |
YPAO multi-point measurement |
Yes |
YPAO Volume |
Yes |
Adaptive DRC (Dynamic Range Control) |
Yes |
Initial Volume & Maximum Volume Setting |
Yes |
A.R.T. Wedge |
N / A |
Pure Direct |
Yes |
DA Converter |
384 kHz / 32-bit BB PCM5102A |
Audio Delay |
Yes (0-500 ms) |
HDMI eARC |
Yes |
HDMI Audio Return Channel |
Yes |
HDMI Pass-through |
8K60B, 4K120AB (via future update)*HDMI1-3 |
HDMI Up-scaling |
Yes up to 4K |
HDMI Up-conversion |
N / A |
HDR 10+ |
Yes (via future update) |
VRR / ALLM / QMS / QFT |
Yes (via future update) |
DTS:X |
Yes |
Rated Output Power (1kHz, 1ch driven) |
150 W (4 ohms, 0.9% THD) |
Analog Audio Input / Output |
4 / 0 |
Digital Audio Input / Output: Optical |
1 / 0 |
DAB Tuner |
Yes (Availability varies by region.) |
USB Input |
Yes |
Network Port |
Yes |
Wi-Fi |
Yes (2.4 / 5 GHz) |
AirPlay |
Yes |
Bluetooth |
Yes (SBC / AAC) |
Front AV Input |
USB |
On-screen display |
Graphical User Interface |
HDMI Input / Output |
7 / 1 |
Digital Audio Input / Output: Coaxial |
1 / 0 |
Phono Input |
Yes |
XLR Terminal |
N / A |
Component Video Input / Output |
N / A |
Composite Video Input / Output |
N / A |
Preout |
2.2-ch |
Headphone Output |
1 |
FM / AM Tuner |
Yes (Availability varies by region.) |
SCENE |
Yes (8 sets) |
RS-232C Interface |
N / A |
MusicCast Surround |
Yes |
Zone Video Output |
N / A |
HDMI CEC |
Yes |
Web Browser Control |
Yes |
Remote Control Unit |
Yes |
Zone 2 Audio Output |
Preout |
Zone 3 Audio Output |
N / A |
Zone 4 Audio Output |
N / A |
Powered Zone |
Zone 2 |
Zone B Output |
N / A |
Dimensions (W x H x D) |
435 W x 171 H x 377 D mm (with antenna up:435W x 245H x 377D mm);17-1/8"W x 6-3/4"H x 14-7/8"D (with antenna up:17-1/8"W x 9-5/8"H x 14-7/8"D) |
App Control |
Yes (iPhone / iPad / Android phone / tablet) |
Zone GUI |
N / A |
+12V Trigger Output |
1 |
Remote (IR) Input / Output |
N / A |
Party Mode |
Yes |
Standby Power Consumption (IR only) |
0.1 W |
Auto Power Standby |
Yes |
ECO mode |
Yes |
Weight |
9.8 kg; 21.6 lbs. |
- 7.2 Channel powerful surround sound with Zone2
- Wi-Fi, Bluetooth®, AirPlay 2, Spotify Connect and MusicCast multi-room audio
- Dolby Atmos® with height virtualization via FW Update
- HDMI™ 7 in/1 out, 8K/60Hz, 4K/120Hz
- Dedicated gaming function(ALLM,VRR,QMS,QFT) via FW update
- Voice control with Alexa and Google Assistant devices. *Availability varies by region
- MusicCast Surround capable – add MusicCast 20 or MusicCast 50 speakers to create wireless surround sound
- YPAO™ Reflected Sound Control (R.S.C.) sound optimisation
UNPARALLELED SOUND
Dolby Atmos® with Height Virtualizer*
Puts you at the center of the action by positioning sounds to different points in your room, including from above. *This function is available via FW update.
CINEMA DSP 3D
Incorporates extensive sound field data from world famous concert halls and music clubs to reproduce the same big theater acoustics within the walls of your home.
Music Enhancer
Restores compressed audio so it sounds the way it was intended to be heard.
High Slew Rate Amplifier
Responds to rapid changes in input level for precise and stable signal transmission.
MOVIES AND GAMES LIKE NEVER BEFORE
HDR10+*
Provides deeper contrast and more realistic images that stay true to the creators’ intent.
8K/60 Hz and 4K/120 Hz*
Enables a higher resolution and refresh rate, giving you a smoother and more realistic viewing experience.
Gaming-dedicated Functions (ALLM,VRR,QMS,QFT)*
Ensure seamless motion and transitions to enhance your performance.
HDMI Multiple Input with Latest Technology*
Multiple HDMI input will equally support the latest HDMI technology to allow next-gen gaming consoles can be connected at the same time.
*These functions are available via firmware update.
SIMPLE TO SET UP, SIMPLE TO USE
MusicCast App
Explore the power of multi-room audio, access your sources and streaming devices, and control your AV receiver, all through your smartphone.
AV Setup Guide App
Offers expert guidance through installation, cable connections, and various other settings.
Voice Control Systems
Works with Alexa and Google Assistant, so your AV receiver is always at your command. Through AirPlay 2, you can stream your music via voice control operation Siri from Apple iOS device. *Availability varies by region.
MADE FOR YOUR ROOM
YPAO™-R.S.C.
Analyzes room acoustics and measures speaker characteristics to calibrate sound according to your room. This feature also adjusts CINEMA DSP parameters according to reflected sounds, so you can have perfectly balanced, professionally calibrated sound.
Wireless Rear Speaker
Gives you the freedom to arrange your rear speakers wirelessly to suit your home décor.
Impressive Design
An iconic design that’s built for performance and style.
